Face Recognition Temperature Measurement Terminal

CPU: RK3399

Display: 8 inch LCD screen, resolution: 800*1280, 10:16

Operating system: Linux Android 7.1 or above

Camera: Binocular camera

Package Size(mm): 322(L)x135(W)x38(H)



Non-contact automatic body temperature detection, brush human face and perform high-precision infrared human temperature acquisition at the same time, fast and high effect.



Company, Community, Hospital, School


CPU RK3399
Display 8 inch LCD screen, resolution: 800*1280, 10:16
Operating system Linux Android 7.1 or above
Camera Binocular camera
Infrared sensor(optional) Within 2 meters, support software pitch adjustment
ID Card Reader(optional) Support for Second Generation ID Identification
Thermal imaging module Temperature measurement accuracy±0.3℃, support 0.5~0.7m
Communication mode WIFI/Bluetooth4.0/Ethernet
Extermal interface Ethernet RJ45 interface, Micro-USB interface, RS485 interface, Wigan interface, Replay interface, Industrial connector output interface
Package Size(mm) 322(L)x135(W)x38(H)
